Please contact us for more photos of SM6T100A
| Part Number | SM6T100A |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 456240 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode TVS Single Uni-Dir 85.5V 600W 2-Pin SMB T R |
| Category | Circuit Protection |
| Family | TVS |
| ROHS Compliant | Yes |
| MSL Level | SM6T100A |
| Datasheet download |  SM6T100A.pdf |
| Part Number | SM6T100A |
|---|---|
| Lead Finish | Matte Tin |
| Rad Hard | No |
| MSL Level | 1 |
| Peak Pulse Power Dissipation | 600 W |
| Operating Temperature | -55 to 150 °C |
| Maximum Peak Pulse Current | 22.5 A |
| Maximum Reverse Stand-off Voltage | 85.5 V |
| Mounting | Surface Mount |
| Direction Type | Uni-Directional |
| Supplier Package | SMB |
| Minimum Breakdown Voltage | 95 V |
| Product Dimensions | 4.6 x 3.95 x 2.45 mm |
| ESD Protection | No |
| Pin Count | 2 |
| Configuration | Single |
| Test Current | 1 mA |
| Maximum Reverse Leakage Current | 0.2 uA |
| Maximum Clamping Voltage | 178 V |
| Max Processing Temp | 260 |
| Package | 2SMB |
| Replacement Part Number | PART-SM6T100A |
| Weight | Contact us |
| Country of Origin | - |
