VNP35NV04-E STMicroelectronics

VNP35NV04-E Images

Please contact us for more photos of VNP35NV04-E

Part Number	VNP35NV04-E
Manufacturer	STMicroelectronics
Quantity in stock	327630 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Power Switch Lo Side 30A 3-Pin(3+Tab) TO-220 Tube
Category	Power Management IC
Family	Power Switch
ROHS Compliant	Yes
MSL Level	VNP35NV04-E
Datasheet download	VNP35NV04-E.pdf

Request Quotation for VNP35NV04-E

VNP35NV04-E Specifications

Part Number	VNP35NV04-E
Lead Finish	Matte Tin
Supplier Package	TO-220
Type	Low Side
Minimum Output Current	30 A
Mounting	Through Hole
Product Dimensions	10.4 x 4.6 x 9.15 mm
Supply Current	0.1 mA
Pin Count	3
Maximum Power Dissipation	125000 mW
Number of Outputs	1
Operating Supply Voltage Range	45 V
Rad Hard	No
Switch On Resistance	0.013 Ohm
Package	3TO-220
Replacement Part Number	PART-VNP35NV04-E
Weight	Contact us
Country of Origin	-
