Please contact us for more photos of B3F3120
| Part Number | B3F3120 |
|---|---|
| Manufacturer | OMRON |
| Quantity in stock | 857200 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Tactile N.O. SPST Flat Plunger PC Pins 0.05A 24VDC 0.98N Thru-Hole Bag |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | B3F3120 |
| Datasheet download |  B3F3120.pdf |
| Part Number | B3F3120 |
|---|---|
| Product Dimensions | 7.3 x 7.4 mm |
| Contact Plating | Gold |
| Mounting | Through Hole |
| Lead Finish | Silver |
| Operating Temperature | -25 to 70 °C |
| Pole Throw Configuration | SPST |
| Switch Configuration | N.O. |
| Terminal Type | PC Pins |
| Max Processing Temp | 260 |
| Maximum DC Voltage Rating | 24 V |
| Rad Hard | No |
| Type | Miniature |
| Replacement Part Number | PART-B3F3120 |
| Weight | Contact us |
| Country of Origin | - |
