Please contact us for more photos of B3WN6002
| Part Number | B3WN6002 |
|---|---|
| Manufacturer | OMRON |
| Quantity in stock | 763060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Tactile N.O. SPST Round Button PC Pins 0.05A 12VDC 1.96N Thru-Hole Tape |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | B3WN6002 |
| Datasheet download |  B3WN6002.pdf |
| Part Number | B3WN6002 |
|---|---|
| Actuator Style | Round Button |
| Maximum Current Rating | 0.05@12VDC |
| Pole Throw Configuration | SPST |
| Type | Dust-Proof |
| Mechanical Life | 100000 |
| Max Processing Temp | 260 |
| Operating Force | 1.96 |
| Switch Configuration | N.O. |
| Mounting | Through Hole |
| Terminal Type | PC Pins |
| Maximum DC Voltage Rating | 12 |
| Rad Hard | No |
| Product Dimensions | 8 x 8 x 13 mm |
| Operating Temperature | -25 to 85 °C |
| Replacement Part Number | PART-B3WN6002 |
| Weight | Contact us |
| Country of Origin | - |
