Please contact us for more photos of EVPAA302K
| Part Number | EVPAA302K |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 445830 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Tactile N.O. SPST Rectangular Button J-Bend 0.02A 15VDC 1.6N SMD Embossed T R |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | EVPAA302K |
| Datasheet download |  EVPAA302K.pdf |
| Part Number | EVPAA302K |
|---|---|
| Switch Configuration | N.O. |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Type | Light Touch |
| Mounting | Surface Mount |
| Product Dimensions | 4.3 x 2.9 x 1.7 mm |
| Terminal Type | J-Bend |
| Maximum DC Voltage Rating | 15 V |
| Maximum Current Rating | 0.02@15VDC A |
| Actuator Style | Rectangular Button |
| Pole Throw Configuration | SPST |
| Replacement Part Number | PART-EVPAA302K |
| Weight | Contact us |
| Country of Origin | - |
