Please contact us for more photos of EVPAEDB2A
| Part Number | EVPAEDB2A |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 352110 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Tactile N.O. SPST Rectangular Button J-Bend 20A 250VAC15VDC 200000Cycles 3N SMD Embossed T R |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | EVPAEDB2A |
| Datasheet download |  EVPAEDB2A.pdf |
| Part Number | EVPAEDB2A |
|---|---|
| Maximum AC Voltage Rating | 250 V |
| Mechanical Life | 200000 Cycles |
| Actuator Style | Rectangular Button |
| Rad Hard | No |
| Pin Count | 2 |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Switch Configuration | N.O. |
| Mounting | Surface Mount |
| Pole Throw Configuration | SPST |
| Product Dimensions | 4.8 x 2.9 x 2.6 |
| Type | Light Touch |
| Maximum DC Voltage Rating | 15 V |
| Replacement Part Number | PART-EVPAEDB2A |
| Weight | Contact us |
| Country of Origin | - |
