Please contact us for more photos of EVQ11U04M
| Part Number | EVQ11U04M |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 572720 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Tactile N.O. SPST Round Button PC Pins 0.02A 15VDC 2.6N Thru-Hole Radial T R |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | EVQ11U04M |
| Datasheet download |  EVQ11U04M.pdf |
| Part Number | EVQ11U04M |
|---|---|
| Actuator Style | Round Button |
| Type | Light Touch |
| Operating Temperature | -20 to 70 °C |
| Product Dimensions | 6 x 6 x 4.3 mm |
| Mounting | Through Hole |
| Pole Throw Configuration | SPST |
| Switch Configuration | N.O. |
| Terminal Type | PC Pins |
| Lead Finish | Gold|Silver |
| Maximum DC Voltage Rating | 15 V |
| Maximum Current Rating | 0.02@15VDC A |
| Max Processing Temp | 250 to 260 |
| Rad Hard | No |
| Replacement Part Number | PART-EVQ11U04M |
| Weight | Contact us |
| Country of Origin | - |
