Please contact us for more photos of EVQP2602W
| Part Number | EVQP2602W |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 818800 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Tactile N.O. SPST Button J-Bend 0.02A 15VDC 3.5N SMD Embossed T R |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | EVQP2602W |
| Datasheet download |  EVQP2602W.pdf |
| Part Number | EVQP2602W |
|---|---|
| Pole Throw Configuration | SPST |
| Terminal Type | J-Bend |
| Switch Configuration | N.O. |
| Maximum Current Rating | 0.02@15VDC A |
| Type | Light Touch |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 85 °C |
| Mounting | Surface Mount |
| Product Dimensions | 3.5 x 5.5 x 2.5 mm |
| Lead Finish | Gold|Silver |
| Maximum DC Voltage Rating | 15 V |
| Replacement Part Number | PART-EVQP2602W |
| Weight | Contact us |
| Country of Origin | - |
