Part Number | EVQP2K02Q |
---|---|
Manufacturer | Panasonic |
Quantity in stock | 189500 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Switch Tactile N.O. SPST Round Button J-Bend 0.02A 15VDC 3.5N SMD Embossed T R |
Category | Switches and Relays |
Family | Switches |
ROHS Compliant | Yes |
MSL Level | EVQP2K02Q |
Datasheet download | ![]() |
Part Number | EVQP2K02Q |
---|---|
Terminal Type | J-Bend |
Mounting | Surface Mount |
Pole Throw Configuration | SPST |
Maximum DC Voltage Rating | 15 V |
Maximum Current Rating | 0.02@15VDC A |
Product Dimensions | 3.5 x 5.5 x 2.5 mm |
Lead Finish | Gold|Silver |
Switch Configuration | N.O. |
Rad Hard | No |
Operating Temperature | -40 to 85 °C |
Max Processing Temp | 260 |
Type | Light Touch |
Replacement Part Number | PART-EVQP2K02Q |
Weight | Contact us |
Country of Origin | - |
