Please contact us for more photos of EVQPAE09K
| Part Number | EVQPAE09K |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 237640 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Tactile N.O. SPST Round Button PC Pins 0.02A 15VDC 1.6N Thru-Hole Bulk |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | EVQPAE09K |
| Datasheet download |  EVQPAE09K.pdf |
| Part Number | EVQPAE09K |
|---|---|
| Type | Light Touch |
| Operating Temperature | -20 to 70 °C |
| Terminal Type | PC Pins |
| Actuator Style | Round Button |
| Rad Hard | No |
| Switch Configuration | N.O. |
| Product Dimensions | 6 x 7.8 x 9.5 mm |
| Pole Throw Configuration | SPST |
| Max Processing Temp | 250 to 260 |
| Maximum DC Voltage Rating | 15 V |
| Maximum Current Rating | 0.02@15VDC A |
| Mounting | Through Hole |
| Lead Finish | Gold|Silver |
| Replacement Part Number | PART-EVQPAE09K |
| Weight | Contact us |
| Country of Origin | - |
