Please contact us for more photos of B32521N8223K189
| Part Number | B32521N8223K189 |
|---|---|
| Manufacturer | TDK |
| Quantity in stock | 517450 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.022uF 630V PET 10% (13 X 5 X 11mm) Radial 10mm 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | B32521N8223K189 |
| Datasheet download |  B32521N8223K189.pdf |
| Part Number | B32521N8223K189 |
|---|---|
| Termination Style | Radial |
| Lead Pitch For Radial | 10 mm |
| Voltage(AC) | 200 V |
| Tolerance | 10 % |
| Capacitance Value | 0.022 uF |
| Seated Plane Height | 11 mm |
| Lead Finish | Matte Tin |
| Dielectric | PET |
| Rad Hard | No |
| Voltage(DC) | 630 V |
| Max Processing Temp | 260 |
| Package/Case | 13(Max) X 5(Max) X 11(Max) |
| Operating Temperature | -55 to 125 °C |
| Product Dimensions | 13 x 5 x 11 mm |
| Mounting | Through Hole |
| Product Depth | 5(Max) mm |
| Product Height | 11(Max) mm |
| Product Length | 13(Max) mm |
| Replacement Part Number | PART-B32521N8223K189 |
| Weight | Contact us |
| Country of Origin | - |
