Please contact us for more photos of B32522C6334J000
| Part Number | B32522C6334J000 |
|---|---|
| Manufacturer | TDK |
| Quantity in stock | 768410 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.33uF 400V PET 5% (18 X 8.5 X 14.5mm) Radial 15mm 125\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | B32522C6334J000 |
| Datasheet download |  B32522C6334J000.pdf |
| Part Number | B32522C6334J000 |
|---|---|
| Termination Style | Radial |
| Mounting | Through Hole |
| Rad Hard | No |
| Tolerance | 5 % |
| Product Dimensions | 18 x 8.5 x 14.5 mm |
| Lead Finish | Matte Tin |
| Seated Plane Height | 14.5 mm |
| Operating Temperature | -55 to 125 °C |
| Max Processing Temp | 260 |
| Voltage(DC) | 400 V |
| Lead Pitch For Radial | 15 mm |
| Package/Case | 18(Max) X 8.5(Max) X 14.5(Max) |
| Voltage(AC) | 200 V |
| Dielectric | PET |
| Capacitance Value | 0.33 uF |
| Product Depth | 8.5(Max) mm |
| Product Height | 14.5(Max) mm |
| Product Length | 18(Max) mm |
| Replacement Part Number | PART-B32522C6334J000 |
| Weight | Contact us |
| Country of Origin | - |
