Please contact us for more photos of 1-1586037-0
| Part Number | 1-1586037-0 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 233180 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Power HDR 10 POS 4.2mm Solder ST Thru-Hole 10 Terminal 1 Port |
| Category | Connectors |
| Family | Connector Power |
| ROHS Compliant | Yes |
| MSL Level | 1-1586037-0 |
| Datasheet download |  1-1586037-0.pdf |
| Part Number | 1-1586037-0 |
|---|---|
| Termination Method | Solder |
| Housing Material | Nylon |
| Pitch | 4.2 mm |
| Operating Temperature | -40 to 105 °C |
| Body Orientation | Straight |
| Mounting | Through Hole |
| Contact Material | Brass |
| Contact Plating | Tin |
| Max Processing Temp | 240|260|265 |
| Lead Finish | Tin |
| Gender | HDR |
| Rad Hard | No |
| Family Name | VAL-U-LOK Connectors |
| Product Dimensions | 22.2 x 9.75 x 12.8 mm |
| Product Depth | 9.75 mm |
| Product Height | 12.8 mm |
| Product Length | 22.2 mm |
| Replacement Part Number | PART-1-1586037-0 |
| Weight | Contact us |
| Country of Origin | - |
