Please contact us for more photos of 100616-1
| Part Number | 100616-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 473340 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn RJ-45 F 8 POS 2.54mm Solder ST Thru-Hole 8 Terminal 1 Port Blister Pack Cat 3 |
| Category | Connectors |
| Family | Connector Telephone and Telecom |
| ROHS Compliant | Yes |
| MSL Level | 100616-1 |
| Datasheet download |  100616-1.pdf |
| Part Number | 100616-1 |
|---|---|
| Pitch | 2.54 mm |
| Contact Plating | Gold Over Nickel |
| Rad Hard | No |
| Contact Material | Phosphor Bronze |
| Gender | F |
| Termination Method | Solder |
| Family Name | RJ45 Modular Jacks & Plugs |
| Mounting | Through Hole |
| Lead Finish | Tin/Lead |
| Number of Contacts | 8 |
| Body Orientation | Straight |
| Product Dimensions | 18 x 13.4 x 16.71 |
| Type | RJ-45 |
| Housing Material | Polybutylene Terephthalate |
| Max Processing Temp | 240|260|265 |
| Number of Ports | 1 |
| Number of Terminals | 8 |
| Product Depth | 13.4 mm |
| Product Height | 16.71 mm |
| Product Length | 18 mm |
| Replacement Part Number | PART-100616-1 |
| Weight | Contact us |
| Country of Origin | - |
