Please contact us for more photos of 103233-7
| Part Number | 103233-7 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 230920 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Unshrouded Header HDR 16 POS 2.54mm Press Fit ST Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 103233-7 |
| Datasheet download |  103233-7.pdf |
| Part Number | 103233-7 |
|---|---|
| Termination Method | Press Fit |
| Body Orientation | Straight |
| Housing Color | Black |
| Mounting | Through Hole |
| Product Dimensions | 19.91 x 4.87 x 10.41 mm |
| Operating Temperature | -55 to 125 °C |
| Gender | HDR |
| Pitch | 2.54 mm |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Rad Hard | No |
| Contact Plating | Gold Over Nickel |
| Lead Finish | Matte Tin/Lead |
| Product Depth | 4.87 mm |
| Product Height | 10.41 mm |
| Product Length | 19.91 mm |
| Replacement Part Number | PART-103233-7 |
| Weight | Contact us |
| Country of Origin | - |
