Please contact us for more photos of 131197
| Part Number | 131197 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 730570 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn TNC F 0Hz to 11GHz 50Ohm Crimp ST Panel Mount |
| Category | Connectors |
| Family | Connector RF |
| ROHS Compliant | Yes |
| MSL Level | 131197 |
| Datasheet download |  131197.pdf |
| Part Number | 131197 |
|---|---|
| Terminate To | RG 174/188/KX43/KX22 Cable |
| Rad Hard | No |
| Gender | F |
| Impedance | 50 Ohm |
| Operating Frequency | 0 to 11 GHz |
| Mounting | Panel Mount |
| Termination Method | Crimp |
| Operating Temperature | -65 to 165 °C |
| Type | TNC |
| Body Orientation | Straight |
| Product Length | 24.35 mm |
| Replacement Part Number | PART-131197 |
| Weight | Contact us |
| Country of Origin | - |
