| Part Number | 1565359-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 742120 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Fine Pitch Connector PL 100 POS 0.5mm Solder ST SMD T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 1565359-1 |
| Datasheet download |  1565359-1.pdf |
| Part Number | 1565359-1 |
|---|---|
| Rad Hard | No |
| Max Processing Temp | 245 |
| Contact Material | Copper Alloy |
| Contact Plating | Gold Over Nickel |
| Number of Rows | 2 |
| Housing Material | Nylon 6T |
| Pitch | 0.5 mm |
| Gender | PL |
| Termination Method | Solder |
| Product Dimensions | 28.8 x 4.3 x 3.35 mm |
| Mounting | Surface Mount |
| Lead Finish | Tin |
| Housing Color | Black |
| Body Orientation | Straight |
| Type | Fine Pitch Connector |
| Product Depth | 4.3 mm |
| Product Height | 3.35 mm |
| Product Length | 28.8 mm |
| Replacement Part Number | PART-1565359-1 |
| Weight | Contact us |
| Country of Origin | - |
