Please contact us for more photos of 170286-1
| Part Number | 170286-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 297100 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Contact SKT Crimp ST Cable Mount Strip |
| Category | Connectors |
| Family | Connector Terminals |
| ROHS Compliant | Yes |
| MSL Level | 170286-1 |
| Datasheet download |  170286-1.pdf |
| Part Number | 170286-1 |
|---|---|
| Body Orientation | Straight |
| Termination Method | Crimp |
| Rad Hard | No |
| Shielded | No |
| Lead Finish | Tin |
| Gender | SKT |
| Wire Size | 14 to 20 AWG |
| Product Dimensions | 21.5 x 4.6 x 4.9 mm |
| Contact Type | Signal |
| Contact Material | Phosphor Bronze |
| Connector Type | Connector Headers and PCB Receptacles |
| Mounting | Cable Mount |
| Contact Plating | Pre-Tin |
| Product Depth | 4.6 mm |
| Product Height | 4.9 mm |
| Product Length | 21.5 mm |
| Replacement Part Number | PART-170286-1 |
| Weight | Contact us |
| Country of Origin | - |
