Please contact us for more photos of 3-641120-2
| Part Number | 3-641120-2 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 171970 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 2 POS 3.96mm Solder ST Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 3-641120-2 |
| Datasheet download |  3-641120-2.pdf |
| Part Number | 3-641120-2 |
|---|---|
| Termination Method | Solder |
| Housing Color | White |
| Pitch | 3.96 mm |
| Product Dimensions | 7.92 x 7.62 x 13.34 mm |
| Lead Finish | Tin |
| Mounting | Through Hole |
| Body Orientation | Straight |
| Maximum Voltage Rating | 600 |
| Max Processing Temp | 240|260|265 |
| Gender | HDR |
| Type | Wire to Board |
| Contact Plating | Gold Over Nickel |
| Contact Material | Copper Alloy |
| Rad Hard | No |
| Maximum Contact Resistance | 3 |
| Housing Material | Polyester |
| Number of Rows | 1 |
| Operating Temperature | -55 to 105 °C |
| Family Name | Mass Termination Assembly (MTA) Connectors |
| Maximum Current Rating | 7/Contact |
| Product Depth | 7.62 mm |
| Product Height | 13.34 mm |
| Product Length | 7.92 mm |
| Replacement Part Number | PART-3-641120-2 |
| Weight | Contact us |
| Country of Origin | - |
