Please contact us for more photos of 5-103414-8
| Part Number | 5-103414-8 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 253110 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 10 POS 2.54mm Solder ST Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 5-103414-8 |
| Datasheet download |  5-103414-8.pdf |
| Part Number | 5-103414-8 |
|---|---|
| Max Processing Temp | 240 |
| Operating Temperature | -55 to 105 °C |
| Contact Plating | Gold Over Nickel |
| Mounting | Through Hole |
| Contact Material | Copper Alloy |
| Product Dimensions | 28.45 x 5.77 x 13.94 mm |
| Housing Material | Thermoplastic |
| Termination Method | Solder |
| Housing Color | Black |
| Body Orientation | Straight |
| Lead Finish | Tin |
| Pitch | 2.54 mm |
| Gender | HDR |
| Product Depth | 5.77 mm |
| Product Height | 13.94 mm |
| Product Length | 28.45 mm |
| Replacement Part Number | PART-5-103414-8 |
| Weight | Contact us |
| Country of Origin | - |
