Please contact us for more photos of 5-104549-9
| Part Number | 5-104549-9 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 822620 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 80 POS 1.27mm Solder ST SMD Tube |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 5-104549-9 |
| Datasheet download |  5-104549-9.pdf |
| Part Number | 5-104549-9 |
|---|---|
| Termination Method | Solder |
| Gender | HDR |
| Mounting | Surface Mount |
| Max Processing Temp | 245|260 |
| Lead Finish | Tin |
| Body Orientation | Straight |
| Housing Color | Black |
| Operating Temperature | -65 to 105 °C |
| Rad Hard | No |
| Contact Material | Phosphor Bronze |
| Housing Material | Thermoplastic |
| Product Dimensions | 56.99 x 8.73 x 11.12 mm |
| Contact Plating | Gold Over Nickel |
| Pitch | 1.27 mm |
| Product Depth | 8.73 mm |
| Product Height | 11.12 mm |
| Product Length | 56.99 mm |
| Replacement Part Number | PART-5-104549-9 |
| Weight | Contact us |
| Country of Origin | - |
