Please contact us for more photos of 5103310-1
| Part Number | 5103310-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 390760 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 10 POS 2.54mm Solder RA Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 5103310-1 |
| Datasheet download |  5103310-1.pdf |
| Part Number | 5103310-1 |
|---|---|
| Product Dimensions | 20.32 x 12.31 x 9.14 mm |
| Pitch | 2.54 mm |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Termination Method | Solder |
| Contact Plating | Gold |
| Housing Color | Black |
| Body Orientation | Right Angle |
| Mounting | Through Hole |
| Max Processing Temp | 240|260|265 |
| Lead Finish | Tin |
| Gender | HDR |
| Operating Temperature | -65 to 105 °C |
| Product Depth | 12.31 mm |
| Product Height | 9.14 mm |
| Product Length | 20.32 mm |
| Replacement Part Number | PART-5103310-1 |
| Weight | Contact us |
| Country of Origin | - |
