Please contact us for more photos of 5146025-1
| Part Number | 5146025-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 765800 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn PCMCIA HDR 68 POS 2.54mm Solder RA Thru-Hole 5A |
| Category | Connectors |
| Family | Connector Memory Card |
| ROHS Compliant | Yes |
| MSL Level | 5146025-1 |
| Datasheet download |  5146025-1.pdf |
| Part Number | 5146025-1 |
|---|---|
| Termination Method | Solder |
| Product Dimensions | 79.79 x 6.98 mm |
| Family Name | PC Card Connectors (PCMCIA Compliant) |
| Number of Contacts | 68 |
| Type | PCMCIA |
| Maximum Current Rating | 5 |
| Mounting | Through Hole |
| Contact Material | Brass |
| Body Orientation | Right Angle |
| Operating Temperature | -10 to 70 °C |
| Lead Finish | Tin |
| Gender | HDR |
| Max Processing Temp | 245|260 |
| Number of Rows | 2 |
| Contact Plating | Gold Over Nickel |
| Rad Hard | No |
| Pitch | 2.54 mm |
| Housing Material | Liquid Crystal Polymer |
| Product Height | 6.98 mm |
| Product Length | 79.79 mm |
| Replacement Part Number | PART-5146025-1 |
| Weight | Contact us |
| Country of Origin | - |
