Part Number | 5177984-5 |
---|---|
Manufacturer | TE Connectivity |
Quantity in stock | 284070 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn Fine Pitch Connector PL 120 POS 0.8mm Solder ST SMD Tube |
Category | Connectors |
Family | Connector Headers and PCB Receptacles |
ROHS Compliant | Yes |
MSL Level | 5177984-5 |
Datasheet download | 5177984-5.pdf |
Part Number | 5177984-5 |
---|---|
Rad Hard | No |
Product Dimensions | 53.8 x 6 x 4.6 mm |
Contact Plating | Gold Over Nickel |
Number of Rows | 2 |
Operating Temperature | -40 to 85 °C |
Maximum Voltage Rating | 100 |
Maximum Current Rating | 0.5/Contact |
Type | Fine Pitch Connector |
Gender | PL |
Housing Material | Liquid Crystal Polymer |
Termination Method | Solder |
Housing Color | Natural |
Mounting | Surface Mount |
Maximum Contact Resistance | 30 |
Max Processing Temp | 245|260 |
Lead Finish | Tin |
Body Orientation | Straight |
Contact Material | Brass |
Pitch | 0.8 mm |
Family Name | Free Height (FH) Board-to-Board Connectors |
Product Depth | 6 mm |
Product Height | 4.6 mm |
Product Length | 53.8 mm |
Replacement Part Number | PART-5177984-5 |
Weight | Contact us |
Country of Origin | - |
