5205736-7 TE Connectivity

5205736-7 Images

Please contact us for more photos of 5205736-7

Part Number 5205736-7
Manufacturer TE Connectivity
Quantity in stock 585870 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Conn D-Subminiature SKT 15 POS 2.74mm Solder ST Thru-Hole 15 Terminal 1 Port
Category Connectors
Family Connector D-Subminiature
ROHS Compliant Yes
MSL Level 5205736-7
Datasheet download 5205736-7.pdf
Request Quotation for 5205736-7

5205736-7 Specifications

Part Number 5205736-7
Pitch 2.74 mm
Contact Plating Gold Over Nickel/ Gold Over Palladium Nickel Over Nickel
Product Dimensions 39.52 x 12.93 x 17.8 mm
Gender SKT
Rad Hard No
Contact Material Phosphor Bronze
Termination Method Solder
Housing Material Nylon
Body Orientation Straight
Lead Finish Tin
Mounting Through Hole
Max Processing Temp 240|260|265
Product Depth 12.93 mm
Product Height 17.8 mm
Product Length 39.52 mm
Replacement Part Number PART-5205736-7
Weight Contact us
Country of Origin -
