Please contact us for more photos of 5225395-7
| Part Number | 5225395-7 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 380630 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn BNC PL 0Hz to 4GHz 50Ohm Crimp ST Cable Mount Gold |
| Category | Connectors |
| Family | Connector RF |
| ROHS Compliant | Yes |
| MSL Level | 5225395-7 |
| Datasheet download |  5225395-7.pdf |
| Part Number | 5225395-7 |
|---|---|
| Contact Plating | Gold |
| Body Orientation | Straight |
| Termination Method | Crimp |
| Contact Material | Brass |
| Terminate To | Coaxial Cable |
| Operating Temperature | -65 to 165 °C |
| Operating Frequency | 0 to 4 GHz |
| Mounting | Cable Mount |
| Product Dimensions | 30.94 mm |
| Gender | PL |
| Product Diameter | 14.53 mm |
| Product Length | 30.94 mm |
| Replacement Part Number | PART-5225395-7 |
| Weight | Contact us |
| Country of Origin | - |
