Please contact us for more photos of 5747193-1
| Part Number | 5747193-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 722300 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn D-Subminiature SKT 50 POS 2.76mm Solder RA Thru-Hole 50 Terminal 1 Port |
| Category | Connectors |
| Family | Connector D-Subminiature |
| ROHS Compliant | Yes |
| MSL Level | 5747193-1 |
| Datasheet download |  5747193-1.pdf |
| Part Number | 5747193-1 |
|---|---|
| Number of Terminals | 50 |
| Contact Material | Phosphor Bronze |
| Product Dimensions | 66.92 x 29.28 x 15.36 mm |
| Gender | SKT |
| Rad Hard | No |
| Contact Plating | Gold Over Nickel |
| Termination Method | Solder |
| Housing Material | Nylon |
| Body Orientation | Right Angle |
| Number of Ports | 1 |
| Max Processing Temp | 240|260|265 |
| Pitch | 2.76 mm |
| Type | D-Subminiature |
| Lead Finish | Tin |
| Number of Contacts | 50 |
| Mounting | Through Hole |
| Product Depth | 29.28 mm |
| Product Height | 15.36 mm |
| Product Length | 66.92 mm |
| Replacement Part Number | PART-5747193-1 |
| Weight | Contact us |
| Country of Origin | - |
