Please contact us for more photos of 6469354-1
| Part Number | 6469354-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 550930 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Hard Metric HDR 40 POS 2.5mm Press Fit RA Thru-Hole |
| Category | Connectors |
| Family | Connector Backplane |
| ROHS Compliant | Yes |
| MSL Level | 6469354-1 |
| Datasheet download |  6469354-1.pdf |
| Part Number | 6469354-1 |
|---|---|
| Termination Method | Press Fit |
| Number of Rows | 4 |
| Product Dimensions | 24.9 x 25.55 x 18.19 mm |
| Body Orientation | Right Angle |
| Mounting | Through Hole |
| Number of Contacts | 40 |
| Lead Finish | Tin |
| Gender | HDR |
| Pitch | 2.5 mm |
| Type | Hard Metric |
| Contact Plating | Gold Over Nickel |
| Rad Hard | No |
| Housing Material | Polyester |
| Contact Material | Phosphor Bronze |
| Product Depth | 25.55 mm |
| Product Height | 18.19 mm |
| Product Length | 24.9 mm |
| Replacement Part Number | PART-6469354-1 |
| Weight | Contact us |
| Country of Origin | - |
