Please contact us for more photos of 770580-1
| Part Number | 770580-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 849500 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Housing M 10 POS 4.14mm Crimp ST Cable Mount Individual |
| Category | Connectors |
| Family | Connector Discrete Wire Housing |
| ROHS Compliant | Yes |
| MSL Level | 770580-1 |
| Datasheet download |  770580-1.pdf |
| Part Number | 770580-1 |
|---|---|
| Maximum Voltage Rating | |
| Pitch | 4.14 mm |
| Product Dimensions | 22.4 x 23.83 x 15.19 mm |
| Rad Hard | No |
| Wire Size | 16 to 30 AWG |
| Number of Rows | 2 |
| Mounting | Cable Mount |
| Operating Temperature | -55 to 105 °C |
| Housing Color | White |
| Housing Material | Nylon |
| Maximum Current Rating | 9.5/Contact |
| Number of Contacts | 10 |
| Type | Housing |
| Gender | M |
| Family Name | Micro MATE-N-LOK Wire-Applied Connectors |
| Body Orientation | Straight |
| Product Depth | 23.83 mm |
| Product Height | 15.19 mm |
| Product Length | 22.4 mm |
| Replacement Part Number | PART-770580-1 |
| Weight | Contact us |
| Country of Origin | - |
