Please contact us for more photos of 794120-1
| Part Number | 794120-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 165910 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Power HDR 2 POS 5.08mm Solder RA Thru-Hole 2 Terminal 1 Port |
| Category | Connectors |
| Family | Connector Power |
| ROHS Compliant | Yes |
| MSL Level | 794120-1 |
| Datasheet download |  794120-1.pdf |
| Part Number | 794120-1 |
|---|---|
| Number of Terminals | 2 |
| Pitch | 5.08 mm |
| Termination Method | Solder |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Housing Material | Nylon |
| Type | Power |
| Gender | HDR |
| Operating Temperature | -55 to 85 °C |
| Body Orientation | Right Angle |
| Max Processing Temp | 240|260|265 |
| Contact Material | Phosphor Bronze |
| Number of Ports | 1 |
| Mounting | Through Hole |
| Product Dimensions | 15.24 x 8.76 mm |
| Rad Hard | No |
| Product Height | 8.76 mm |
| Product Length | 15.24 mm |
| Replacement Part Number | PART-794120-1 |
| Weight | Contact us |
| Country of Origin | - |
