Please contact us for more photos of DMC-MD-84-W-01
| Part Number | DMC-MD-84-W-01 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 270440 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn DMC-MD Series, 4-Module Receptacle, Flange Mount, Black Keyed (1) |
| Category | Connectors |
| Family | Connector Rectangular |
| ROHS Compliant | Yes |
| MSL Level | DMC-MD-84-W-01 |
| Datasheet download |  DMC-MD-84-W-01.pdf |
| Part Number | DMC-MD-84-W-01 |
|---|---|
| Operating Temperature | -55 to 175 °C |
| Rad Hard | No |
| Housing Color | Black |
| Pin Count | 80 |
| Number of Contacts | 80 |
| Housing Material | Aluminum alloy |
| Body Orientation | Straight |
| For Use With | |
| Number of Rows | 1 |
| Gender | RCP |
| Type | |
| Mounting | Flange Mount |
| Replacement Part Number | PART-DMC-MD-84-W-01 |
| Weight | Contact us |
| Country of Origin | - |
