Please contact us for more photos of ADS1191IPBSR
| Part Number | ADS1191IPBSR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 891870 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | AFE General Purpose 1ADC 16-Bit 1.8V 3V 32-Pin TQFP T R |
| Category | Communication |
| Family | Analog Front End |
| ROHS Compliant | Yes |
| MSL Level | ADS1191IPBSR |
| Datasheet download |  ADS1191IPBSR.pdf |
| Part Number | ADS1191IPBSR |
|---|---|
| Number of ADC Inputs | 1 |
| Category | General Purpose |
| Supplier Package | TQFP |
| Lead Finish | Gold |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| MSL Level | 2 |
| Pin Count | 32 |
| Product Dimensions | 5 x 5 x 1 mm |
| Maximum Operating Supply Voltage | 3.6|5.25 V |
| Mounting | Surface Mount |
| Type | General Purpose |
| Number of ADCs | 1 |
| Typical Operating Supply Voltage | 1.8|3 V |
| Typical Supply Current | 0.25 mA |
| Power Supply Type | Analog|Digital |
| Resolution | 24 Bit |
| Number of Channels per Chip | 1 |
| Sampling Rate | 8 ksps |
| Interface Type | Serial (SPI) |
| Screening Level | Industrial |
| Minimum Operating Supply Voltage | 1.7|2.7 V |
| Package | 32TQFP |
| Replacement Part Number | PART-ADS1191IPBSR |
| Weight | Contact us |
| Country of Origin | - |
