Please contact us for more photos of AMC1200SDUBR
| Part Number | AMC1200SDUBR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 747800 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | SP Amp ISOL Amp Single 5.5V 8-Pin SOP T R |
| Category | Amplifiers IC |
| Family | SP Amplifier |
| ROHS Compliant | Yes |
| MSL Level | AMC1200SDUBR |
| Datasheet download |  AMC1200SDUBR.pdf |
| Part Number | AMC1200SDUBR |
|---|---|
| Maximum Dual Supply Voltage | 5.5 V |
| Rad Hard | No |
| Minimum Dual Supply Voltage | 2.7|4.5 V |
| Mounting | Surface Mount |
| Number of Channels per Chip | 1 |
| Supplier Package | SOP |
| Max Processing Temp | 260 |
| MSL Level | 3 |
| Screening Level | Extended Industrial |
| Rail to Rail | No |
| Type | Isolation Amplifier |
| Product Dimensions | 9.5 x 6.57 x 3.3 mm |
| Operating Temperature | -40 to 105 °C |
| Lead Finish | Gold |
| Maximum Supply Current | 5.4@5/[email protected] mA |
| Power Supply Type | Dual |
| Minimum DC Continuous Isolation Voltage | 4000 V |
| Pin Count | 8 |
| Minimum CMRR | 95 dB |
| Minimum PSRR | 61 dB |
| Package | 8SOP |
| Replacement Part Number | PART-AMC1200SDUBR |
| Weight | Contact us |
| Country of Origin | - |
