Please contact us for more photos of DRV8305NPHP
| Part Number | DRV8305NPHP |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 518450 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | 3-Phase Gate Driver IC 4.4V to 45V 48-Pin HTQFP Tube |
| Category | Power Management IC |
| Family | Motion Motor Control |
| ROHS Compliant | Yes |
| MSL Level | DRV8305NPHP |
| Datasheet download |  DRV8305NPHP.pdf |
| Part Number | DRV8305NPHP |
|---|---|
| MSL Level | 3 |
| Supplier Package | HTQFP |
| Maximum Operating Current | 23 to 27 mA |
| Product Dimensions | 7 x 7 x 1.05(Max) |
| Mounting | Surface Mount |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 125 °C |
| Type | 3-Phase Gate Driver IC |
| Operating Supply Voltage | 4.4 to 45 V |
| Lead Finish | Gold Over Nickel Palladium |
| Pin Count | 48 |
| Package | 48HTQFP |
| Replacement Part Number | PART-DRV8305NPHP |
| Weight | Contact us |
| Country of Origin | - |
