DS92001TMAX NOPB Texas Instruments

Please contact us for more photos of DS92001TMAX NOPB

Part Number	DS92001TMAX NOPB
Manufacturer	Texas Instruments
Quantity in stock	485610 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LVDS Buffer 0.5V 8-Pin SOIC N T R
Category	Interface IC
Family	LVDS
ROHS Compliant	Yes
MSL Level	DS92001TMAX NOPB
Datasheet download	DS92001TMAX NOPB.pdf

Request Quotation for DS92001TMAX NOPB

DS92001TMAX NOPB Specifications

Part Number	DS92001TMAX NOPB
Number of Drivers	1
Maximum Input Current	20 uA
Input Type	CML\|LVDS\|LVPECL
Differential Input Low Threshold Voltage	-0.07 V
Operating Temperature	-40 to 85 °C
Max Processing Temp	260
Transmission Data Rate	400 Mbps
Typical Operating Supply Voltage	3.3 V
Rad Hard	No
Supplier Package	SOIC N
Number of Receivers	1
Lead Finish	Matte Tin
Differential Input High Threshold Voltage	-0.005 V
Number of Elements per Chip	1
Minimum Operating Supply Voltage	3 V
Maximum Operating Supply Voltage	3.6 V
Mounting	Surface Mount
Product Dimensions	4.9 x 3.9 x 1.45 mm
MSL Level	1
Pin Count	8
Screening Level	Industrial
Output Type	Buffer
Maximum Propagation Delay Time	2 ns
Maximum Power Dissipation	726 mW
Maximum Differential Output Voltage	0.5 V
Package	8SOIC N
Replacement Part Number	PART-DS92001TMAX NOPB
Weight	Contact us
Country of Origin	-
