Please contact us for more photos of INA101AM
| Part Number | INA101AM |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 883980 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | SP Amp INSTR Amp Single \u00b120V 10-Pin TO-100 Tube |
| Category | Amplifiers IC |
| Family | SP Amplifier |
| ROHS Compliant | Yes |
| MSL Level | INA101AM |
| Datasheet download |  INA101AM.pdf |
| Part Number | INA101AM |
|---|---|
| Lead Finish | Gold |
| Rad Hard | No |
| Rail to Rail | No |
| Minimum Dual Supply Voltage | ±5 V |
| Maximum Input Bias Current | 0.02@±15V uA |
| Power Supply Type | Dual |
| Operating Temperature | -25 to 85 °C |
| Product Dimensions | 8.96 x 8.96 x 4.4 mm |
| Maximum Dual Supply Voltage | ±20 V |
| Number of Channels per Chip | 1 |
| Type | Instrumentation Amplifier |
| Pin Count | 10 |
| Maximum Voltage Gain | 60 dB |
| Mounting | Through Hole |
| Supplier Package | TO-100 |
| Package | 10TO-100 |
| Replacement Part Number | PART-INA101AM |
| Weight | Contact us |
| Country of Origin | - |
