Please contact us for more photos of INA114AU 1K
| Part Number | INA114AU 1K |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 784480 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | SP Amp INSTR Amp Single \u00b118V 16-Pin SOIC T R |
| Category | Amplifiers IC |
| Family | SP Amplifier |
| ROHS Compliant | Yes |
| MSL Level | INA114AU 1K |
| Datasheet download |  INA114AU 1K.pdf |
| Part Number | INA114AU 1K |
|---|---|
| MSL Level | 3 |
| Maximum Input Bias Current | 0.002@±15V uA |
| Maximum Dual Supply Voltage | ±18 V |
| Maximum Voltage Gain | 80 dB |
| Rail to Rail | No |
| Lead Finish | Gold |
| Product Dimensions | 10.28 x 7.52 x 2.35 mm |
| Max Processing Temp | 260 |
| Mounting | Surface Mount |
| Minimum Dual Supply Voltage | ±2.25 V |
| Operating Temperature | -40 to 85 °C |
| Minimum CMRR | 110 dB |
| Rad Hard | No |
| Type | Instrumentation Amplifier |
| Number of Channels per Chip | 1 |
| Pin Count | 16 |
| Supplier Package | SOIC |
| Power Supply Type | Dual |
| Maximum Supply Current | 3@±15V mA |
| Package | 16SOIC |
| Replacement Part Number | PART-INA114AU 1K |
| Weight | Contact us |
| Country of Origin | - |
