Please contact us for more photos of INA126U 2K5
| Part Number | INA126U 2K5 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 833760 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | SP Amp INSTR Amp Single \u00b118V 36V 8-Pin SOIC T R |
| Category | Amplifiers IC |
| Family | SP Amplifier |
| ROHS Compliant | Yes |
| MSL Level | INA126U 2K5 |
| Datasheet download |  INA126U 2K5.pdf |
| Part Number | INA126U 2K5 |
|---|---|
| Power Supply Type | Single|Dual |
| Maximum Dual Supply Voltage | ±18 V |
| Mounting | Surface Mount |
| Number of Channels per Chip | 1 |
| Minimum CMRR | 83 dB |
| Pin Count | 8 |
| Supplier Package | SOIC |
| Screening Level | Industrial |
| Type | Instrumentation Amplifier |
| Rail to Rail | No |
| Lead Finish | Gold |
| Rad Hard | No |
| Minimum Dual Supply Voltage | ±1.35 V |
| Minimum Single Supply Voltage | 2.7 V |
| Max Processing Temp | 260 |
| Maximum Single Supply Voltage | 36 V |
| Product Dimensions | 5 x 4 x 1.5 mm |
| Operating Temperature | -40 to 85 °C |
| MSL Level | 3 |
| Maximum Supply Current | 0.2@±15V mA |
| Package | 8SOIC |
| Replacement Part Number | PART-INA126U 2K5 |
| Weight | Contact us |
| Country of Origin | - |
