Please contact us for more photos of LM2676SX-ADJ NOPB
| Part Number | LM2676SX-ADJ NOPB |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 170690 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 8V to 40V 8-Pin(7+Tab) TO-263 T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | LM2676SX-ADJ NOPB |
| Datasheet download |  LM2676SX-ADJ NOPB.pdf |
| Part Number | LM2676SX-ADJ NOPB |
|---|---|
| Efficiency | 88 % |
| Lead Finish | Matte Tin |
| Minimum Input Voltage | 8 V |
| Maximum Input Voltage | 40 V |
| Rad Hard | No |
| Maximum Output Current | 3 A |
| MSL Level | 3 |
| Max Processing Temp | 245|260 |
| Operating Supply Voltage | 8 to 40 V |
| Pin Count | 8 |
| Output Type | Adjustable |
| Product Dimensions | 10.16 x 8.64 x 4.57 mm |
| Type | Step Down |
| Operating Temperature | -40 to 125 °C |
| Supplier Package | TO-263 |
| Output Voltage | 1.2 to 37 V |
| Switching Frequency | 260 kHz |
| Number of Outputs | 1 |
| Mounting | Surface Mount |
| Switching Regulator | Yes |
| Package | 8TO-263 |
| Replacement Part Number | PART-LM2676SX-ADJ NOPB |
| Weight | Contact us |
| Country of Origin | - |
