Please contact us for more photos of LM2842XMK-ADJL NOPB
| Part Number | LM2842XMK-ADJL NOPB |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 668820 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 4.5V to 42V 6-Pin TSOT T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | LM2842XMK-ADJL NOPB |
| Datasheet download |  LM2842XMK-ADJL NOPB.pdf |
| Part Number | LM2842XMK-ADJL NOPB |
|---|---|
| Switching Frequency | 550 kHz |
| Operating Temperature | -40 to 125 °C |
| Operating Supply Voltage | 4.5 to 42 V |
| Product Dimensions | 2.97 x 1.65 x 0.87 mm |
| Output Type | Adjustable |
| Pin Count | 6 |
| Maximum Output Current | 0.6 A |
| Number of Outputs | 1 |
| Lead Finish | Tin |
| Supplier Package | TSOT |
| Switching Regulator | Yes |
| Minimum Input Voltage | 4.5 V |
| Maximum Input Voltage | 42 V |
| Type | Step Down |
| MSL Level | 1 |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Mounting | Surface Mount |
| Package | 6TSOT |
| Replacement Part Number | PART-LM2842XMK-ADJL NOPB |
| Weight | Contact us |
| Country of Origin | - |
