LM2990T-15 NOPB Texas Instruments

Please contact us for more photos of LM2990T-15 NOPB

Part Number	LM2990T-15 NOPB
Manufacturer	Texas Instruments
Quantity in stock	681640 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LDO Regulator Neg -15V 1.8A 3-Pin(3+Tab) TO-220 Rail
Category	Power Management IC
Family	Linear Regulator
ROHS Compliant	Yes
MSL Level	LM2990T-15 NOPB
Datasheet download	LM2990T-15 NOPB.pdf

Request Quotation for LM2990T-15 NOPB

LM2990T-15 NOPB Specifications

Part Number	LM2990T-15 NOPB
Operating Temperature	-40 to 125 °C
Rad Hard	No
Minimum Input Voltage	-26 V
Line Regulation	60 mV
Typical Dropout Voltage @ Current	0.1@100mA\|0.6@1A V
Max Processing Temp	260
Lead Finish	Matte Tin
Maximum Output Current	1.8 A
Output Voltage	-15 V
Supplier Package	TO-220
Typical Quiescent Current	1 mA
Product Dimensions	10.16 x 4.7 x 8.89 mm
Junction to Ambient	73 °C/W
Function	LDO
Maximum Dropout Voltage @ Current	0.3@100mA\|1@1A V
Number of Outputs	1
Maximum Quiescent Current	5 mA
Accuracy	±5 %
Maximum Input Voltage	0.3 V
MSL Level	1
Pin Count	3
Input Voltage Range	0.3 to -26 V
Polarity	Negative
Screening Level	Automotive
Load Regulation	50 mV
Junction to Case	3 °C/W
Mounting	Through Hole
Output Type	Fixed
Package	3TO-220
Replacement Part Number	PART-LM2990T-15 NOPB
Weight	Contact us
Country of Origin	-
