Please contact us for more photos of LM324KAPWR
| Part Number | LM324KAPWR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 330650 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Quad GP \u00b116V 32V 14-Pin TSSOP T R |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | LM324KAPWR |
| Datasheet download |  LM324KAPWR.pdf |
| Part Number | LM324KAPWR |
|---|---|
| Typical Gain Bandwidth Product | 1.2 MHz |
| Type | General Purpose Amplifier |
| Maximum Input Offset Voltage | 3@30V mV |
| Technology | Bipolar |
| Typical Voltage Gain | 100 dB |
| Supplier Package | TSSOP |
| Maximum Single Supply Voltage | 32 V |
| Maximum Dual Supply Voltage | ±16 V |
| Minimum Dual Supply Voltage | ±1.5 V |
| Pin Count | 14 |
| Typical Input Noise Voltage Density | 35@±15V nV/rtHz |
| Number of Channels per Chip | 4 |
| Minimum CMRR | 65 dB |
| Typical Single Supply Voltage | 5|9|12|15|18|24|28 V |
| Maximum Operating Supply Voltage | ±16|32 V |
| Typical Dual Supply Voltage | ±3|±5|±9|±12|±15 V |
| Rad Hard | No |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Maximum Input Bias Current | 0.1@5V uA |
| Typical Slew Rate | 0.5@±15V V/us |
| Product Dimensions | 5.1 x 4.5 x 1.05 mm |
| Rail to Rail | No |
| Power Supply Type | Single|Dual |
| Shut Down Support | No |
| Operating Temperature | 0 to 70 °C |
| Minimum Single Supply Voltage | 3 V |
| Mounting | Surface Mount |
| Lead Finish | Gold |
| Package | 14TSSOP |
| Replacement Part Number | PART-LM324KAPWR |
| Weight | Contact us |
| Country of Origin | - |
