Please contact us for more photos of LM46000QPWPRQ1
| Part Number | LM46000QPWPRQ1 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 887070 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 3.5V to 60V 16-Pin HTSSOP EP T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | LM46000QPWPRQ1 |
| Datasheet download |  LM46000QPWPRQ1.pdf |
| Part Number | LM46000QPWPRQ1 |
|---|---|
| Switching Frequency | 200 to 2200 kHz |
| Mounting | Surface Mount |
| Pin Count | 16 |
| Operating Supply Voltage | 3.5 to 60 V |
| Screening Level | Automotive |
| Operating Temperature | -40 to 125 °C |
| Output Voltage | 1 to 28 V |
| Type | Step Down |
| Max Processing Temp | 260 |
| Maximum Input Voltage | 60 V |
| MSL Level | 3 |
| Number of Outputs | 1 |
| Lead Finish | Gold Over Nickel Palladium |
| Rad Hard | No |
| Output Type | Adjustable |
| Maximum Output Current | 0.5 A |
| Product Dimensions | 5.1(Max) x 4.5(Max) x 1.05(Max) |
| Minimum Input Voltage | 3.5 V |
| Supplier Package | HTSSOP EP |
| Package | 16HTSSOP EP |
| Replacement Part Number | PART-LM46000QPWPRQ1 |
| Weight | Contact us |
| Country of Origin | - |
