LM5010SDX NOPB Texas Instruments

LM5010SDX NOPB Images

Please contact us for more photos of LM5010SDX NOPB

Part Number LM5010SDX NOPB
Manufacturer Texas Instruments
Quantity in stock 680880 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Conv DC-DC Single Step Down 8V to 75V 10-Pin LLP EP T R
Category Power Management IC
Family DC to DC Converter
ROHS Compliant Yes
MSL Level LM5010SDX NOPB
Datasheet download LM5010SDX NOPB.pdf
Request Quotation for LM5010SDX NOPB

LM5010SDX NOPB Specifications

Part Number LM5010SDX NOPB
Efficiency 91 %
Product Dimensions 4 x 4 x 0.8 mm
MSL Level 1
Lead Finish Matte Tin
Max Processing Temp 260
Type Step Down
Rad Hard No
Operating Temperature -40 to 125 °C
Switching Regulator Yes
Mounting Surface Mount
Operating Supply Voltage 6.6 to 7.4 V
Number of Outputs 1
Output Type Adjustable
Minimum Input Voltage 8 V
Maximum Input Voltage 75 V
Pin Count 10
Switching Frequency 1000 kHz
Output Voltage 2.5 to 70 V
Maximum Output Current 1 A
Supplier Package LLP EP
Package 10LLP EP
Replacement Part Number PART-LM5010SDX NOPB
Weight Contact us
Country of Origin -
