Please contact us for more photos of LM7171BIMX NOPB
| Part Number | LM7171BIMX NOPB |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 176850 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Single Volt Fdbk \u00b118V 36V 8-Pin SOIC N T R |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | LM7171BIMX NOPB |
| Datasheet download |  LM7171BIMX NOPB.pdf |
| Part Number | LM7171BIMX NOPB |
|---|---|
| Typical Dual Supply Voltage | ±3|±5|±9|±12|±15 V |
| Minimum Single Supply Voltage | 5.5 V |
| Maximum Operating Supply Voltage | ±18|36 V |
| Typical Single Supply Voltage | 9|12|15|18|24|28 V |
| Maximum Dual Supply Voltage | ±18 V |
| Maximum Supply Current | 8@±5V mA |
| Product Dimensions | 4.9 x 3.9 x 1.45 mm |
| Type | Voltage Feedback Amplifier |
| Rad Hard | No |
| Maximum Single Supply Voltage | 36 V |
| Screening Level | Industrial |
| Lead Finish | Tin |
| Pin Count | 8 |
| Max Processing Temp | 260 |
| Minimum CMRR | 70 dB |
| Supplier Package | SOIC N |
| Typical Slew Rate | 950@±5V V/us |
| MSL Level | 1 |
| Number of Channels per Chip | 1 |
| Operating Temperature | -40 to 85 °C |
| Minimum Dual Supply Voltage | ±2.75 V |
| Maximum Input Bias Current | 10@±5V uA |
| Typical Voltage Gain | 78 dB |
| Maximum Input Offset Voltage | 3.5@±5V mV |
| Typical NonInverting Input Noise Current Density | 1.8@±5V pA/rtHz |
| Mounting | Surface Mount |
| Typical Input Noise Voltage Density | 14@±5V nV/rtHz |
| Technology | BiCOM |
| Rail to Rail | No |
| Typical Gain Bandwidth Product | 125 MHz |
| Shut Down Support | No |
| Power Supply Type | Single|Dual |
| Minimum PSRR | 75 dB |
| Package | 8SOIC N |
| Replacement Part Number | PART-LM7171BIMX NOPB |
| Weight | Contact us |
| Country of Origin | - |
