LMZ12010TZ NOPB Texas Instruments

LMZ12010TZ NOPB Images

Please contact us for more photos of LMZ12010TZ NOPB

Part Number	LMZ12010TZ NOPB
Manufacturer	Texas Instruments
Quantity in stock	192550 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Module DC-DC 1-OUT 0.8V to 6V 10A 50W 11-Pin TO-PMOD EP Rail
Category	Power Supplies
Family	DC to DC Power Supply
ROHS Compliant	Yes
MSL Level	LMZ12010TZ NOPB
Datasheet download	LMZ12010TZ NOPB.pdf

Request Quotation for LMZ12010TZ NOPB

LMZ12010TZ NOPB Specifications

Part Number	LMZ12010TZ NOPB
MSL Level	3
Lead Finish	Matte Tin
Mounting	Surface Mount
Output Voltage	0.8 to 6 V
Pin Count	11
Number of Outputs	1
Input Voltage	6 to 20 V
Switching Regulator	Yes
Output Power	50 W
Supplier Package	TO-PMOD EP
Product Dimensions	15 x 15 x 5.9 mm
Max Processing Temp	245
Output Current	10 A
Rad Hard	No
Type	Step Down
Package	11TO-PMOD EP
Replacement Part Number	PART-LMZ12010TZ NOPB
Weight	Contact us
Country of Origin	-
