LMZ14201HTZX NOPB Texas Instruments

LMZ14201HTZX NOPB Images

Please contact us for more photos of LMZ14201HTZX NOPB

Part Number	LMZ14201HTZX NOPB
Manufacturer	Texas Instruments
Quantity in stock	293610 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Simple Switcher Power Module 7-Pin TO-PMOD EP T R
Category	Power Supplies
Family	Power Misc
ROHS Compliant	Yes
MSL Level	LMZ14201HTZX NOPB
Datasheet download	LMZ14201HTZX NOPB.pdf

Request Quotation for LMZ14201HTZX NOPB

LMZ14201HTZX NOPB Specifications

Part Number	LMZ14201HTZX NOPB
Lead Finish	Matte Tin
Category	Simple Switcher Power Module
Type	Simple Switcher Power Module
Supplier Package	TO-PMOD EP
Mounting	Surface Mount
Pin Count	7
Product Dimensions	10.16 x 9.85 x 4.57 mm
MSL Level	3
Max Processing Temp	245
Operating Temperature	-40 to 125 °C
Rad Hard	No
Package	7TO-PMOD EP
Replacement Part Number	PART-LMZ14201HTZX NOPB
Weight	Contact us
Country of Origin	-
