Please contact us for more photos of LP2951-30DR
| Part Number | LP2951-30DR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 681870 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | LDO Regulator Pos 1.235V to 30V3V 0.1A 8-Pin SOIC T R |
| Category | Power Management IC |
| Family | Linear Regulator |
| ROHS Compliant | Yes |
| MSL Level | LP2951-30DR |
| Datasheet download |  LP2951-30DR.pdf |
| Part Number | LP2951-30DR |
|---|---|
| Line Regulation | 0.2 %/V |
| Product Dimensions | 5 x 4 x 1.5 mm |
| Junction to Ambient | 97 °C/W |
| Load Regulation | 0.2 % |
| Operating Temperature | -40 to 125 °C |
| Max Processing Temp | 260 |
| Lead Finish | Gold |
| Rad Hard | No |
| Typical Dropout Voltage @ Current | 0.05@100uA|0.38@100mA V |
| Typical Quiescent Current | 0.075 mA |
| Polarity | Positive |
| Maximum Output Current | 0.1 A |
| Supplier Package | SOIC |
| Mounting | Surface Mount |
| Screening Level | Extended |
| Function | LDO |
| Minimum Input Voltage | 2 V |
| Number of Outputs | 1 |
| Accuracy | ±1.4 % |
| Input Voltage Range | 30 to 2 V |
| Output Type | Adjustable|Fixed |
| Maximum Input Voltage | 30 V |
| Maximum Dropout Voltage @ Current | 0.08@100uA|0.45@100mA V |
| MSL Level | 1 |
| Output Voltage | 1.235 to 30|3 V |
| Pin Count | 8 |
| Reference Voltage | 1.252 V |
| Package | 8SOIC |
| Replacement Part Number | PART-LP2951-30DR |
| Weight | Contact us |
| Country of Origin | - |
