Please contact us for more photos of MSP430F169IRTDR
| Part Number | MSP430F169IRTDR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 773580 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 16-bit MSP430 RISC 60KB Flash 3.3V 64-Pin VQFN EP T R |
| Category | Microcontrollers MCU IC |
| Family | 16 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | MSP430F169IRTDR |
| Datasheet download |  MSP430F169IRTDR.pdf |
| Part Number | MSP430F169IRTDR |
|---|---|
| Program Memory Type | Flash |
| Lead Finish | Matte Tin |
| Supplier Package | VQFN EP |
| Number of Timers | 2 |
| Instruction Set Architecture | RISC |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Pin Count | 64 |
| Product Dimensions | 9 x 9 x 0.88 mm |
| Max Processing Temp | 260 |
| Mounting | Surface Mount |
| MSL Level | 3 |
| Operating Supply Voltage | 3.3 V |
| Analog Comparators | 1 |
| Program Memory Size | 60 KB |
| Watchdog | 1 |
| RAM Size | 2 KB |
| Data Bus Width | 16 Bits |
| Maximum Operating Supply Voltage | 3.6 V |
| Maximum Speed | 8 MHz |
| Minimum Operating Supply Voltage | 3 V |
| Device Core | |
| Interface Type | I2C/SPI/UART/USART |
| Screening Level | Industrial |
| On-Chip DAC | 2-chx12-bit |
| Number of Programmable I/Os | 48 |
| Display Driver | |
| LCD Segments | |
| On-Chip ADC | 8-chx12-bit |
| Package | 64VQFN EP |
| Replacement Part Number | PART-MSP430F169IRTDR |
| Weight | Contact us |
| Country of Origin | - |
