OPA191IDBVR Texas Instruments

Please contact us for more photos of OPA191IDBVR

Part Number	OPA191IDBVR
Manufacturer	Texas Instruments
Quantity in stock	392810 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	OP Amp Single Low Power R-R I O \u00b118V 36V 5-Pin SOT-23 T R
Category	Amplifiers IC
Family	OP Amp
ROHS Compliant	Yes
MSL Level	OPA191IDBVR
Datasheet download	OPA191IDBVR.pdf

Request Quotation for OPA191IDBVR

OPA191IDBVR Specifications

Part Number	OPA191IDBVR
Typical Single Supply Voltage	5\|9\|12\|15\|18\|24\|28 V
Minimum CMRR	120 dB
Minimum Single Supply Voltage	4.5 V
Typical Voltage Gain	140 dB
Maximum Dual Supply Voltage	±18 V
Package Dimensions	2.9 x 1.6 x 1.3 mm
Typical Dual Supply Voltage	±3\|±5\|±9\|±12\|±15 V
Moisture Sensitivity Level	2
Rail to Rail	Rail to Rail Input/Output
Supplier Package	SOT-23
Lead Finish	Gold Over Nickel Palladium
Typical NonInverting Input Noise Current Density	0.0015@36V pA/rtHz
Pin Count	5
Maximum Input Offset Voltage	0.05@±18V mV
Minimum Dual Supply Voltage	±2.25 V
Type	Low Power Amplifier
Maximum Supply Current	0.2@36 mA
Typical Gain Bandwidth Product	2.5 MHz
Power Supply Type	Single\|Dual
Technology	CMOS
Rad Hard	No
Number of Channels per Chip	1
Minimum PSRR	-130.45 dB
Mounting	Surface Mount
Shut Down Support	No
Maximum Single Supply Voltage	36 V
Typical Input Noise Voltage Density	53@36V nV/rtHz
Maximum Operating Supply Voltage	36\|±18 V
Operating Temperature	-40 to 125 °C
Typical Slew Rate	7.5@36V V/us
Maximum Input Bias Current	0.00002@36V uA
Maximum Processing Temperature	260 °C
Screening Level	Extended Industrial
Package	5SOT-23
Replacement Part Number	PART-OPA191IDBVR
Weight	Contact us
Country of Origin	-
